CoreMatrix

Support the following products:

CoreMatrix

Supported Components

The CoreMatrix firmware includes the following user-facing packages:

  • Module: The module package for M-BUS expansion modules.

  • Unit: The unit package containing Unit drivers.

  • Chain: The chain package for Chain devices.

Board Features

CoreMatrix supports the following built-in functions and peripherals:

  • 16 x 16 LED matrix output through M5.Display.

  • Three button inputs through M5.BtnA, M5.BtnB, and M5.BtnC.

  • BMI270 accelerometer and gyroscope readings through M5.Imu.

  • Buzzer tone output through M5.Speaker.

  • Battery, VBUS, charging, and external output power management through M5.Power.
